CSL Series Power Amplifiers
Page 11
Power
Output Power:
The following specifications are guar-
anteed minimums for standard 1 kHz power from 120
VAC, 60 Hz North American units. For additional infor-
mation and power specifications for international units,
see the power matrices on the pages that follow.
460 CSL
Stereo mode (both channels driven):
240 watts into 4 ohms.
200 watts into 8 ohms.
Bridge-Mono mode:
455 watts into 8 ohms.
395 watts into 16 ohms.
Parallel-Mono mode:
455 watts into 2 ohms.
400 watts into 4 ohms.
800 CSL
Stereo mode (both channels driven):
425 watts into 4 ohms.
300 watts into 8 ohms.
Bridge-Mono mode:
900 watts into 8 ohms.
645 watts into 16 ohms.
Parallel-Mono mode:
905 watts into 2 ohms.
640 watts into 4 ohms.
1400 CSL
Stereo mode (both channels driven):
700 watts into 4 ohms.
500 watts into 8 ohms.
Bridge-Mono mode:
1,500 watts into 8 ohms.
1,075 watts into 16 ohms.
Parallel-Mono mode:
1,515 watts into 2 ohms.
1,050 watts into 4 ohms.
Load Impedance: Safe with all types of loads. Rated
for 4 to 8 ohms in Stereo, 8 to 16 ohms in Bridge-Mono
and 2 to 4 ohms in Parallel-Mono mode.
Required AC Mains: 50 to 60 Hz; 100, 120, 220, 230
and 240 VAC (±10%) units are available. All draw
90 watts or less at idle. Current, frequency and voltage
requirements are provided on each unit’s back panel.
460 CSL
: 100 and 120 VAC units draw up to 6 amps of
current; 220 and 240 VAC units draw up to 3 amps.
800 CSL
: 100 and 120 VAC units draw up to 10 amps
of current; 220 and 240 VAC units draw up to 5 amps.
1400 CSL
: 100 and 120 VAC units draw up to 15 amps
of current; 220 and 240 VAC units draw up to 7 amps.
4 Specifications
The following applies to units in Stereo mode with 8 ohm loads and
an input sensitivity of 26 dB unless otherwise specified.
Standard 1 kHz Power: refers to maximum average power in watts
at 1 kHz with 0.1% THD.
Full Bandwidth Power: refers to maximum average power in watts
from 20 Hz to 20 kHz with 0.1% THD.
120 VAC, 60 Hz Units: refers to amplifiers with dedicated trans-
formers for 120 VAC, 60 Hz power mains.
International Units: refers to amplifiers with special multi-tap trans-
formers that make them configurable for several AC mains voltages
and line frequencies.
Performance
Frequency Response: ±0.1 dB from 20 Hz to 20 kHz
at 1 watt.
Phase Response: ±10 degrees from 10 Hz to 20 kHz
at 1 watt.
Signal-to-Noise Ratio: A-weighted, better than 105 dB
below full bandwidth power. No weighting, better than
100 dB below full bandwidth power.
Total Harmonic Distortion (THD): Less than 0.05% at
full bandwidth power from 20 Hz to 1 kHz increasing
linearly to 0.1% at 20 kHz.
Intermodulation Distortion (IMD): (60 Hz and 7 kHz)
Less than 0.05% from less than 158 milliwatts to full
bandwidth power.
Damping Factor: Greater than 1,000 from 10 Hz to
400 Hz.
Crosstalk
460 CSL
: Greater than 75 dB below full bandwidth power
from 50 Hz to 2 kHz, rising linearly to greater than 60 dB at
20 kHz.
800 CSL
: Greater than 90 dB below full bandwidth power
from 50 Hz to 2 kHz, rising linearly to greater than 66 dB at
20 kHz.
1400 CSL
: Greater than 90 dB below full bandwidth power
from 50 Hz to 4 kHz, rising linearly to greater than 70 dB at
20 kHz.
Slew Rate: Greater than 13 volts per microsecond.
Voltage Gain: 20:1 ±3% or 26 dB ±0.25 dB at the maxi-
mum level setting.
460 CSL
: 51:1 ±12% or 34.3 dB ±1 dB at 0.775 volt sensi-
tivity; 28:1 ±12% or 29.1 dB ±1 dB at 1.4 volt sensitivity.
800 CSL
: 64:1 ±12% or 36.2 dB ±1 dB at 0.775 volt sensi-
tivity; 35:1 ±12% or 31.0 dB ±1 dB at 1.4 volt sensitivity.
1400 CSL
: 83:1 ±12% or 38.4 dB ±1 dB at 0.775 volt sen-
sitivity; 46:1 ±12% or 33.3 dB ±1 dB at 1.4 volt sensitivity.
