OPERATION AND SERVICE INFORMATION
25
Owner’s Manual and Service Guide
Fig.13 Lubrication Points-Early Production
Fig.14 Lubrication Points-Late Production
HARDWARE
Periodically, the vehicle should be inspected for loose fasteners. Fasteners should be tightened in accordance
with the Torque Specifications table (Ref Fig. 15).
Bolt
Grad
e
Bolt size D/MM
6 8 10 12 14 16 18 20
Torque （N·M）
4.8 4-5 10-12 20-25 35-44 54-69 99-108 118-147 167-206
