CE2000TX Power Amplifier
Operation Manual
8 Specifications
Minimum Guaranteed Power
120 VAC, 60 Hz Units, Stereo mode, per channel, both channels driven
1 kHz with < 0.5% THD
Dual, 4 ohms (per ch.)
Dual, 8 ohms (per ch.)
660 W
400W
120 VAC, 60 Hz Units, Bridge mono mode
1 kHz with 0.1% THD
Bridge mono, 8 ohms 1,320 W
Performance
Frequency Response (at 1 watt, 20Hz - 25 kHz) < ±0.2 dB
Phase Response (at 1 watt, 20Hz - 20 kHz) < ±15°
Signal to Noise Ratio below rated power (20 Hz to 20 kHz) > 100 dB
Total Harmonic Distortion (THD) at rated power, from 20 Hz to 20 kHz 0.5%
Intermodulation Distortion (IMD) 60 Hz and 7 kHz at 4:1,
from 163 milliwatts to full bandwidth power < 0.1%
Damping Factor: 10 Hz to 400 Hz > 400
Crosstalk (below rated power, 20 Hz to 20 kHz) > 55 dB
Common Mode Rejection (CMR) (20 Hz to 1 kHz) > 70 dB
DC Output Offset (Shorted input) ±10 mV
Input Impedance nominally balanced, nominally unbalanced 20 k ohms, 10 k ohms
Load Impedance (Note: Safe with all types of loads)
Stereo
Bridge Mono
4 and 8 ohms
8 ohms
Voltage Gain (at maximum level setting)
26dB sensitivitiy
1.4V sensitivity
26 dB
32.1 dB
Required AC Mains (configured country-specific) 50/60 Hz, 100 - 240 VAC
Power Draw at Idle 90 watts
Cooling Proportional speed fan
Dimensions: Width, Height, Depth EIA Standard 19 in. (48.3 cm) x 5.25 in. (13.34 cm) x 12.25 in. (31.11 cm)
Net Weight, Shipping Weight 40.3 lb (18.28 kg), 46.4 lb (20.98 kg)
