page 17
Macro-Tech MA-3600VZ Power Amplifier
Operation Manual
6 Specifications
Performance (continued)
Output Impedance See Figure 6.5
Load Impedance (Note: Safe with all types of loads)
Stereo
Bridge Mono
Parallel Mono
2-8 ohms
4-8 ohms
1-2 ohms
Voltage Gain (8-ohm load, rated output at 1 kHz, maximum level setting)
0.775V sensitivity
1.4V sensitivity
26 dB sensitivity
124.6:1 ±6% or 41.9 dB ±0.5 dB
69.2:1 ± 6% or 36.8 dB ±0.5 dB
20:1 ±6% or 26 dB ±0.5 dB
Required AC Mains 50/60 Hz; 100-, 120-, and 230 - VAC (±10%) units are avail-
able. 230 VAC, 50/60 Hz units can be used with 220 and 240
VAC. 100 and 120 VAC units can draw up to 30 amps; 230
VAC units can draw up to 15 amps. Current, voltage and fre-
quency requirements are provided on the unit’s back panel.
Power Draw at Idle 90 watts or less
Construction
Cooling Internal heat sinks with forced-air cooling for rapid, uniform
heat dissipation
Dimensions
Width
Height
Depth (behind mounting surface)
EIA Standard 19-inch rack mount (EIA RS-310-B)
3.5 inch (8.9 cm)
16 inch (40.6 cm)
Weight
Center of gravity is 6 inches (15.2 cm) behind the front mounting surface.
120 VAC, 60 Hz Units
Net
Shipping
100 VAC, International Units
Net
Shipping
120 VAC, International Units
Net
Shipping
230 VAC, International Units
Net
Shipping
54 pounds, 5 ounces (24.7 kg)
63 pounds, 0.5 ounces (28.6 kg)
55 pounds, 1.5 ounces (25.0 kg)
63 pounds, 10 ounces (28.9 kg)
55 pounds, 1.5 ounces (25.0 kg)
63 pounds, 10 ounces (28.9 kg)
53 pounds, 6 ounces (24.2 kg)
61 pounds, 15 ounces (28.1 kg)
