Macro-Tech MA-3600VZ Power Amplifier
Operation Manual
3.4 Choose Input Wire
and Connectors
Figure 3.3 shows connector pin assignments for
balanced wiring, and Figure 3.4 shows connec-
tor pin assignments for unbalanced wiring.
NOTE: Custom wiring should only be
performed by qualified personnel.
Balanced Line
Unbalanced Line
Figure 3.3 Balanced Input
Connector Wiring
Figure 3.4 Unbalanced Input
Connector Wiring
3 Setup
