CSA RA 350 - Heater Placement; Minimum Clearances from Combustibles

Form I-RA/D 350/500, Page 8
Heater
Placement
Do not attempt to install this heater until you have read and under-
stand this manual!
Placement is critical to the efcient operation of this heater.
Locate a specic central area for placement of your heater.
Measure all distances to comply with the specic code requirements and
minimum clearances listed below.
Refer to the section on Venting your heater for vent requirements and
recommendations.
Locate the heater so that suitable means shall be provided to facilitate
regular cleaning and maintenance of the heater (i.e. permanent platform,
portable stairs, ladder, etc.).
WARNING: You must comply with all requirements on
distance from heater to combustibles.
In Canada, for additional information on installation clearances, refer
to CAN/CSA-B139-M91, “Installation Code for Oil Burning Equipment,”
Clause 7.0 - Installation Clearances.
WARNING: Clearances apply to all combustibles. Do
not leave paper, rags, or any moveable combustibles
near the heater or store gasoline or any other
ammable uid near this appliance.
Fan Models Blower Models
RA350/500 RAD350/500
inches mm inches mm
Top 6 152 6 152
Front 48 1219 48 1219
Side (Burner)* 18 457 18 457
Side (Opposite
Burner)*
18 457 18 457
Rear* 24 610 6 152
Bottom 18 457 18 457
Flue Pipe 18 457 18 457
*Allow for service access.
Minimum
Clearances
from
Combustibles
