DigiAir Pro 3

Panel Integrations

Your device will come pre-conﬁgured to connect to the panel using pin triggering. In

My Base it will show Panel Type = pins only.

A panel can also be connected using

• Dial Capture (PSTN Modem)

• TTL

• RS232 (including ATS 7090)

• RS485

• Ethernet

To enable any of these connections to a control panel, install the appropriate cabling

then go to the My Base App and select the correct panel type. See Panel Integrations

for more information.

Panel guides can be found by

• Clicking the panel type (after selection) via the My Base App

• Scanning the QR code below

• Visit the Installer Zone on our website.

PIN TRIGGERING

For this operation, the device is triggered by removing or applying zero volts to input

terminals 1-8. No external pull-up resistors will be required. This is generally

achieved via the digital communicator outputs of a control panel. On receiving an

input to the pin terminals, the unit will signal alarm conditions and will generate the

relevant messages and forward them via the Gemini Global Platform to the ARC.

Installers are advised that the intended use should avoid situations where the rate of

trigger exceeds the rate at which messages are received at the ARC receiver.

Control Panel DigiAir Pro 3
