CSO MS39 AS-OCT - Page 27

MS-39 AS-OCT| IFU302EN00 - 03/2019
INSTRUCTIONS FOR USE
This document is the property of
CSO Costruzione Strumenti Oftalmici srl.
Any reproduction, even partial, it is prohibited.
25/52
Pos
Denomination
Description
A
Chin rest
Adjustable height Adjustable
distance between chin and
forehead
B
Protection carter
Protection against accidental
hand crushing.
C
Power supply unit
A cable is provided with the
power supply unit.
D
Sticker pad
Optional (*)
Sticker for right/left
identification.
E
Device AS-OCT
model Ms-39
Composed by a camera unit
equipped with one or several
micro video cameras for
capturing the images. USB cable
for connection between device
and computer.
F
Personal Computer
and application
Software
Application software for image
capture and device management.
G
Protective cover
Place on the device when it is not
in use to protect it from dust.
H
Hex wrench with
screws
I
Package of paper
for chin cup
Papers to be placed on the chin
cup of the chin rest.
J
Ophthalmic table
optional
Adjustable electric support
surface with one or two columns.
Drawer and auxiliary sockets with
fairlead.
K
Calibration rod
L
Isolation
transformer
optional
230V/230V for the use of the
non-electro-medical appliances in
the patient area.
For the list of accessories and available models, contact the
Manufacturer or the local Distributor.
