CSO MS39 AS-OCT - Technical Data

MS-39 AS-OCT| IFU302EN00 - 03/2019
INSTRUCTIONS FOR USE
This document is the property of
CSO Costruzione Strumenti Oftalmici srl.
Any reproduction, even partial, it is prohibited.
31/52
The accessories must be compliant to the norm IEC 60950-1
Information technology equipment - Safety -
Part 1: General
requirements.
If the accessories are installed in the patient area it is necessary to
install an insulating transformer compliant with th
e directive IEC
60601-1:2005 + A1:2102 - "Medical electrical equipment -
Part 1:
General requirements for basic safety and essential performance".
3.2 TECHNICAL DATA
Technical data
Value
Data transfer
USB 3.0
Mains power
External power supply 24 VCC. In: 100-
240Vac - 50/60Hz - 2A - Out: 24Vdc -
100W
Net cable
with C14 socket
Dimensions (Height x Length x Depth)
505 x 315 x 251 mm
Weight
10.4 kg
Chin rest stroke
70 mm ±1
Minimum height of the chin cup from
the working plan
23 cm
Base movement (x, y, z)
105 x 110 x 30 mm
Working distance
74 mm
Light sources
Technical data
Value
Placido
Led @635 nm
OCT
SLed @845 nm
Pupillography
Led @950 nm
