GENERAL DESCRIPTION
Page 2-4
Evaporator Coil Heater Air Circulator Fans
Figure 2. MCB-1.2 Plenum Area
MCB-1.2
Air Temperature Sensor
Figure 3. MCB-1.2 Air Temperature Sensor Location
Note: CSZ is continuously upgrading the components used
in its equipment. Consequently, the physical appearance of
certain components may vary from that shown.
