CSZ MicroClimate Series - Figure 4. Main Power Wiring, MCB

INSTALLATION
Page 4-5
Controller
Contactor
R-404A
Compressor
Heater
Solid State
Relay
Figure 4. Main Power Wiring, MCB
MCB-1.2
Contactor
R-508B
Compressor
Chamber
High Limit
Note: CSZ is continuously upgrading the components used
in its equipment. Consequently, the physical appearance of
certain components may vary from that shown.
