CSZ MicroClimate Series - Figure 3. Refrigeration Power Pack (MCB 1.2 Cascade)

INSTALLATION
Page 4-4
Air Circulator Motor
R-508B
Compressor
(System #2)
R-404A Compressor (System #1)
Figure 3. Refrigeration Power Pack MCB 1.2 (Cascade)
MCB-1.2
Note: CSZ is continuously upgrading the components used
in its equipment. Consequently, the physical appearance of
certain components may vary from that shown.
