INSTALLATION
Page 4-7
MC-3
Figure 6. EZT 430S Main Power Wiring, MC-3
Contactor R-404A Compressor
Heater Contactor
Humidity Solid State Relay
Contactor R-508B Compressor
Chamber Limit Controller
Controller
Heater Solid State Relay
Note: CSZ is continuously upgrading the components used
in its equipment. Consequently, the physical appearance of
certain components may vary from that shown.
