Chapter 3. LCD Operation
40
November 2001
3.4.7 BERT Test Detail The following displays show the setup screens
under the BERT test Parameter Screen.
BERT TEST PARAMETER
<
B
E
R
T
T
E
S
T
>
P
A
R
A
M
E
T
E
R
Press ENTER
<
B
E
R
T
T
E
S
T
>
F
U
N
C
T
I
O
N
:
O
F
F
Use the arrow keys to browse the available options for BERT test setting.
The details are as follows:
Function; Off or On, default Off. Use to start BERT.
Channel; E1 or Data. Default is E1.
Pattern; 511, 2047, 2e15-1, 2e20-1, QRSS, 2e23-1, All 1, All 0, Alt, 0011, 3in24,
1in16, 1in8, or 1in4. Default is 511.
Err Ins; NONE, Single,10e-1, 10e-2, 10e-3, 10e-4, 10e-5, 10e-6, or 10e-7. Default is
NONE.
Result; display the received error bit count and error rate.
BERT TEST ERROR INSERT (SINGLE)
B
E
R
T
T
E
S
T
<
E
R
R
I
N
S
:
S
I
N
G
L
E
>
When selecting the Single Error insert the following screen will display.
B
E
R
T
S
I
N
G
L
E
E
R
R
.
I
N
S
E
R
T
[
E
N
T
E
R
]
Press ENTER each time you want to insert an error.
