SERVICE - 8
Seat Bar Mechanism Repair
•After the screws have been removed from the seat bar mechanism, it can
swing freely. Be careful not to get your fingers or a hand jammed under
the bar mechanism during this operation.
•If the seat base is to be removed, please refer to SERVICE-8-1 Seat Base
Repair.
Follow the steps in SERVICE-7 Seat Repair to remove the seat.
1.Locate the rear fender and locking pin of the seat bar mechanism.
2.Push the rear fender outwards carefully to separate it from the seat bar mechanism.
3.Use an Allen key or driver to remove the socket head screws (5mm #10, 2pcs) on each
side of the holding board.
4.Remove the socket head screws (25mm #10, 4pcs) on each side of the bar mechanism.
5.Take lift off the seat bar mechanism.
※For re-installation, please follow the exact reverse sequence of these steps.
※This operation could also be carried out without removing the seat base. However the
assembly is much more difficult to handle and is much heavier with the seat in place.
※For seat spring repair, please refer to SERVICE-7-1 Seat Spring Repair.
