SERVICE - 8 - 3
Seat Locking Pin Repair
Please refer to SERVICE-8-1 Seat Base Repair to remove the seat base, then :
1.Loosen the quick-release screw.
2.Take the quick-release screw out.
3.Remove the top washer.
4.Remove the seat locking pin and spring from the other side of the seat base.
5.Take out the seat spring.
※When reassembling, follow the exact reverse sequence of these steps.
Note for re-installation :
When re-installing, apply a little silicon oil to the pin, see the rectangular area shown in
the picture on the right.
