SERVICE - 1 - 6
Steering Head Charger Socket Repair :
Refer to SERVICE-1 Steering Cover Repair steps as follows :
1.Find the steering head charger socket and connector.
2.Remove the steering head charger connector.
3.Use a cross-head screwdriver to remove the charger socket screws (8mm, 2PCS) on
the outside of the steering head.
4.Take out the complete steering head charger socket.
※After the replacement of parts or re-installation, please follow the exact reverse sequence
for reassembly.
※Lithium battery charger socket has 4 holes; the Lead-acid battery charger socket has
3 holes.
•After changing the battery type from lead-acid to lithium, or vice-versa,
make sure that the steering head charger socket SERVICE-6-1
and battery
pack charger sockets match the type of battery installed.
•Self-modification of charging cables or plugs and sockets is extremely
dangerous and can lead to short circuits and even fire.
