250+-25kgf-cm
SERVICE - 2
Steering Bar Repair
•Step 5. If it cannot be removed or replaced easily, use a rubber hammer
to drive bar into position.
•After cutting (steps 2 and 3), when re-installing, use a new cable tie and
place it in the original position.
Remove covers as shown in SERVICE-3 Front Lamp Cover Repair, SERVICE-9 Front
Lower Cover Repair, SERVICE-10 Front Top Cover Repair, and SERVICE-11 Rear
Top Cover Repair.
Then proceed as follows below :
1.Remove the rear frame - left side hook (2 pcs) main cable.
2.Cut and remove the cable tie (2 pcs) of the front frame at the left side.
3.Cut and remove the cable tie (2 pcs) at the front end of the front frame.
4.Remove the two hexagon screws (#6/40mm, 2pcs) connected to the frame and the
steering bar.
5.Push the steering bar upwards for removal.
6.Take out the steering bar.
※After the replacement of parts or re-installation, please follow the exact reverse sequence
for reassembly.
