SERVICE - 2 - 1
Main Cable Repair :
Follow the SERVICE-2 Steering Bar Repair steps and then
1.Please refer to SERVICE-1-2 Buzzer Repair / SERVICE-1-3 Starter VR Repair
to remove the buzzer and VR controller.
2.Insert the front end of the main cable into the hole on the top of the steering bar.
3.Remove the adjustment screw.
4.Disengage the central locking pin to separate the steering bar into upper and lower
sections.
5.Remove the main cable from the upper section of the steering bar.
6.Remove the main cable from the lower section of the steering bar.
7.Take out the main cable and the complete steering bar.
※After the replacement of parts or re-installation, please follow the exact reverse sequence
for reassembly.
