1
FW : 0.0.01
DB : 0.0.01
2
GAS: 00,000 KG
> AUTOMATIC
RECOVERY
VACUUM
3
GASR: T:
- - - - - - - - - - - - - - - - -
G: 0.0.01 P: 0.0.01
T: 0.0.01 O: 00000
5.4 “AUTOMATIC” operation
This function allows the system to perform the complete cycle, which is comprised of: recovery, recovered oil discharge, vacuum
phase, leak test, oil lling, UV tracer charge and refrigerant charge to restore the A/C system of the vehicle with the necessary
quantities of uids, using the SD card database of the unit, or by the operator entering the values.
The automatic cycle can be performed in two ways:
1- Automatic cycle through the database.
2- Automatic cycle by the operator.
The automatic cycle through the database allows the unit to perform all the operations using the rst-installation information
contained in the memory card.
The automatic cycle by the operator allows executing all the operations with the operator selecting the values of the uids to be
recharged.
AUTOMATIC CYCLE EXECUTION THROUGH THE DATABASE
- Connect the high and low pressure pipes to the A/C system
- Open the HP and LP valves, or if there is only one service point, open the corresponding valve.
- Select “AUTOMATIC” with the “+ ↑” e “- ↓ ” buttons. Press OK to start the cycle.
Move in the database using the up “+ ↑” e down “- ↓ ” arrows to select the model involved and press the OK button. To go back,
press the ESC button for 2 sec.
Select the brand (Fig.1), select the model (Fig.2), select the equipment (Fig.3), view the quantity of fluids and oil viscosity (Fig.4),
then press OK to confirm. Move the cursor “>” (Fig.5) to UV if you want to add the tracer or to “Start cycle” to start the operation.
1
MANUAL
> ALFA
AUDI
BMW
2
> 147
156
159
GT
3
> 2.0 JTS
1.9 JTD
1.8 JTD 16V
3.2 GTA
4
GAS : 500 g
OIL : 21 g
ISO 46
5
GAS : 500 g
OIL : 21 g
UV : NO
> Start Cycle
