-34-
ENGINE CYLINDER HEAD & VALVES
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 KH-25 351 01-S Lifter, Valve 2
2 KH-12 755 81-S Kit, Cylinder Head (Model 1515) (Incl. 3-17, 1
Carburetor Gasket (2), Air Cleaner Base
Gasket, Exhaust Manifold Gasket)
KH-12 755 94-S Kit, Cylinder Head (Model 1517) (Incl. 3-17, 1
Carburetor Gasket (2), Air Cleaner Base
Gasket, Exhaust Manifold Gasket)
3 KH-12 411 01-S Rod, Push (Model 1515) 2
KH-12 411 03-S Rod, Push (Model 1517) 2
4 KH-12 041 10-S Gasket, Cylinder Head 1
5 KH-12 017 01-S Valve, Intake (Std.) 1
6 KH-12 016 01-S Valve, Exhaust (Std.) 1
7 KH-25 139 60-S Plug, Allen Hd. 1/8” Pipe 1
8 KH-12 318 19-S Cylinder Head (Model 1515) 2
KH-12 318 36-S Cylinder Head (Model 1517) 2
9 KH-25 186 01-S Arm, Rocker 2
10 KH-12 599 03-S Pivot, Rocker Arm 2
11 KH-M-640034-S Screw, Hex. Flange M6 x 1.0 x 34 2
12 KH-66 032 05-S Seal, Valve Stem 2
13 KH-12 089 34-S Spring, Valve 2
14 KH-12 173 01-S Cap, Valve Spring 2
15 KH-12 755 03-S Kit, Retainer 2
16 KH-12 468 05-S Washer, Plain 13/32” 1
17 KH-12 112 13-S Spacer, Head Bolt Exhaust Port 1
18 KH-12 086 15-S Screw, Hex. Flange M10 x 1.5 x 81 5
19 KH-25 237 14-S Clamp, Hose 2
20 KH-12 326 03-S Hose, Breather 1
21 KH-M-645020-S Screw, Hex. Flange M6 x 1.0 x 20 5
22 KH-12 096 07-S Cover, Valve W/nipple 1
23 KH-M-545010-S Screw, Hex. Flange M5 x 0.8 x 10 1
24 KH-12 018 01-S Retainer, Breather Reed 1
25 KH-12 402 02-S Reed, Breather 1
— KH-12 017 02-S Valve, Intake (.25) 1
— KH-12 016 02-S Valve, Exhaust (.25) 1
— KH-12 041 01-S Gasket, Carburetor 2
— KH-12 041 02-S Gasket, Air Cleaner Base 1
— KH-12 041 03-S Gasket, Exhaust Manifold 1
