Cub Cadet 1515 Pars Manual

-4-
DRIVE SYSTEM
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 17840 Bracket, Mounting, Transaxle 2
2 618-0365 Hub Assembly, Wheel 2
3 618-0667 Transmission, Hydrostatic 1
4 629-0949A Harness Assembly, Ground & Reverse 1
5 683-0251 Bracket Assembly, Idler, Center Dbl 1
6 710-0176 Hex Cap Screw, 5/16-18, 2.75, Gr5 4
7 710-0227 Screw, #8-18, 0.500 2
8 710-0344 Hex Cap Screw, 3/8-16, 1.50, Gr5 3
9 710-0604A Screw, 5/16-18, 0.625 6
10 710-0653 Screw, 1/4-20, 0.375 1
11 710-3007 Screw, #12-24, 0.375 3
12 710-3011 Hex Cap Screw, 3/8-16, 2.25, Gr5 1
13 710-3103 Hex Cap Screw, 5/16-18, 2.00, Gr5 1
14 711-0677 Ferrule, 5/16-18 x .312 Dia 1
15 711-0832 Ferrule, 3/8-24 x .375 Dia 1
16 712-0291 Nut, Hex Lock, 1/4-20 1
17 712-0333 Nut, Hex, 1/2-20, Gr2 1
18 712-0431 Nut, Flange Lock, 3/8-16 3
19 712-1329 Nut, 3/4-16, Grb, Hx 2
20 712-3004A Nut, Flange Lock, 5/16-18, Gr5 5
21 712-3010 Nut, Hex, 5/16-18, Gr5 1
22 712-3017 Nut, Hex, 3/8-16, Gr8 4
23 714-0104 Pin, Cotter, .072 Dia. x 1.13 Lg 2
24 714-0111 Pin, Cotter, 3/32, 1.0 1
25 725-0157 Cable, Tie, 3/16 x .05 x 7.4 2
26 725-1644 Switch, Spring, Short 1
27 726-0154 Tie, Cable, Push Mount 7.5 Lg 1
28 726-0320 Plate, Insulator Nut 1
29 731-1449A Fan, Blade, 10” 1
30 732-0209 Spring, .48 OD x 2.03 Extension 1
31 732-0429A Spring, Extension, .50 Dia x 3.97 Lg 1
32 732-0716 Spring, Extension, .59 OD x 4.00 Lg 1
33 732-0729 Ring, Wire 1
34 732-0994 Spring, Extension, .500 Dia x 7.0 Lg 1
35 732-3118 Spring, Extension, 3/8 OD x 1.44 Lg 1
36 736-0140 Washer, Flat, .385 x .62 x .063 3
37 736-0169 Washer, Lock, 3/8 , Regular Duty 2
38 736-0275 Washer, Flat, .344 x .688 x .065 1
39 736-0921 Washer, Lock, 1/2 , Regular Duty 1
40 736-3010 Washer, Flat, .407 x .812 x .135 Hdn 1
41 738-0372B Spacer, Shoulder, 1.00 x .38 x .38 1
42 747-1149 Rod, Hydro Bypass 1
43 747-1150 Rod, Brake, Hydro 1
44 747-1151 Rod, Control, Hydro 1
45 750-0535 Spacer, .376 ID x .625 OD x .22 1
46 754-0640 Belt, V Type, Poly 1
47 756-0116 Pulley, Idler, V Type x 3.06 Dia 2
48 756-0981A Pulley, Idler, Flat 2.75 OD 1
49 756-1166 Pulley, Input, 5.0 Dia 1
50 783-0810 Bracket, Transmission, Torque Hydro 1
51 783-1019 Bracket, Actuator, Switch 1
52 756-0639 Pulley, Engine, 3.56 Dia
