TIRES/WHEELS/SPACING/BALLAST
69
FRONT WHEEL ADJUSTMENT
The front wheels are tightened with six bolts for MFD to the axle hubs.
Torques for wheel bolts and tie rod end nuts as follows:
Check the bolts to keep them tight at the intervals recommended in the
Service Chart in this manual.
NOTE: The front wheel of tires must always be assembled with the
valve side out.
BOLTS AND NUTS POSITIONS
Front wheel disc
to axle hub bolts
Tie rod end nuts
TORQUE
147 to 166 Nm (109 to 123 LB FT)
59 to 88 Nm (43 to 65 LB FT)
109 to 123 LB FT
(147 to 166 Nm)
