Cub Cadet 7532

1 Hydraulic System
10
3 Disassembly of Hydraulic Block
4 External hydraulic circuit
This block can provide on external hydraulic circuit for loader use or other applications.
Remove the bolt, turn the plate from "O" side to "S" side, and mount with bolt.
Remove the plug P and N and connect the hose. (Plug size: R3/8)
Plug
O-ring
Shim
Spring
Poppet
Housing
Reliefvalve
Taperplug
Plate
Shaft
PR8W4-006
NP
S
O
NP
S
O
WithplateonOside
R3/8
Plate
R3/8
WithplateonSside
Bolt
PR8W4-007
