2 Installation and Removal of Engine Parts
20
34. Hold the lower part of the clutch housing with the
stand.
35. Remove the clutch housing and mounting bolts for
the engine rear plate.
36. Hang the engine assembly with the chain block and
remove the engine assembly.
CAUTION
When holding the lower part of the clutch housing
with the stand, set it in the position where the
clutch housing would not fall off from the stand.
Stand
GZ3W21-035
GZ3W21-036
Clutchhousing
Clutchhousing
Engineassembly
Stand
Clutchhousing
GZ3W21-037
Engineassembly
