Periodic Maintenance and Adjustment 8-31
1. V-belt case drain plug
Cleaning the spark arrester
Be sure the exhaust pipe and muffler are
cool before cleaning the spark arrester.
1. Remove the bolts.
1. Bolt(×3)
2. Remove the tailpipe by pulling it out of
the muffler.
3. Tap the tailpipe lightly, and then use a
wire brush to remove any carbon
deposits from the spark arrester portion
of the tailpipe and inside of the tailpipe
housing.
