damping, and in direction F to decrease the
rebound damping force and thereby soften
the damping.
1. Rebound damping force adjusting screw
Control Functions 4-29
Compression damping force
Turn the compression damping force
adjusting screw (use 3.0 allen wrench) in
direction ⓐ to increase the compression
damping force and thereby harden the
damping, and in direction ⓑ to decrease the
compression damping force and thereby
soften the damping.
a) Compression damping force adjusting screw
