4-4 Control Functions
Low-Range Indicator Light “L”
This indicator light comes on when the drive
select lever is in the “L” position.
Mechanical Parking Brake Indicator Light
“ ”
This indicator light comes on when the
mechanical parking brake is applied.
High-Range Indicator Light “H”
This indicator light comes on when the drive
select lever is in the “H” position.
Neutral Indicator Light “N”
This indicator light comes on when the drive
select lever is in the “N” position.
Reverse Indicator Light “R”
This indicator light comes on when the drive
select lever is in the “R” reverse position.
Coolant Temperature Warning Light ”
When the coolant temperature reaches a
specified level, this light comes on to warn
that the coolant temperature is too hot. If
the light comes on during operation, stop the
engine as soon as it is safe to do so and
allow the engine to cool down for about 15
minutes.
CAUTION:
The engine may overheat if the vehicle is
overloaded. If this happens, reduce the
load to specification.
After restarting, make sure that the light
