Cub Cadet LT 2180 Parts Manual

-24-
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 BS-691694 Gasket, Intake 1
2 BS-808396 Body, Upper Carburetor 1
3 BS-808399 Kit, Idle Mixture 1
4 BS-690718 Screw, Throttle Valve 1
5 BS-809062 Shaft, Throttle 1
6 BS-808177 Kit, Idle Speed 1
7 BS-692077 Gasket, Carburetor Body 1
8 BS-690723 Pin, Float Hinge 1
9 BS-808798 Valve, Float Needle 1
10 BS-806134 Valve, Choke 1
11 BS-808398 Shaft, Choke 1
12 BS-806126 Jet, Main (Standard) 1
13 BS-690720 Screw 4
14 BS-809017 Carburetor 1
15 BS-806132 Valve, Throttle 1
16 BS-806858 Float, Carburetor 1
17 BS-806128 Nozzle, Carburetor 1
18 BS-692056 Screw 4
19 BS-692070 Spring, Governor 1
20 BS-692069 Spring, Governed Idle 1
21 BS-690712 Link, Throttle 1
22 BS-808454 Bracket, Control 1
23 BS-690236 Lever, Governor Control 1
24 BS-690718 Screw, Choke Valve 1
25 BS-692073 Spring, Governor Link 1
26 BS-690721 Bushing, Choke Shaft 1
27 BS-691024 Clamp, Casing 1
28 BS-692083 Screw 1
29 BS-690238 Nut, Governor Control Lever 1
30 BS-690239 Bolt, Governor Control Lever 1
31 BS-690722 Seal, Choke/Throttle Shaft 1
32 BS-806131 Seal, Choke/Throttle Shaft 1
33 BS-691516 Cap, Limiter 1
34 BS-690705 Link, Choke 1
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
CARBURETOR
1
2
3
4
5
6
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
29
30
31
32
33
28
7
34
