Cub Cadet LT 2180 Parts Manual

-28-
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 BS-805101 Seal, Oil (Magneto Side) 1
2 BS-690888 Gasket, Cylinder Head 2
3 BS-809094 Gasket, Breather 1
4 BS-691684 Gasket, Crankcase 1
5 BS-805049 Seal, Oil (PTO Side) 1
6 BS-691694 Gasket, Intake 1
7 BS-692035 Gasket, Intake 2
8 BS-692081 Gasket, Air Cleaner 1
9 BS-690681 Seal, O-Ring (Oil Pump) 1
10 BS-692154 Seal, O-Ring (Crankcase Cover) 1
11 BS-690690 Seal, O-Ring (Oil Pump Screen) 1
12 BS-693172 Seal, Dipstick Tube 1
13 BS-690680 Seal, Governor Shaft 1
14 BS-691963 Seal, Valve 2
15 BS-691613 Gasket, Exhaust 2
16 BS-692063 Gasket, Oil Adapter 1
17 BS-806039 Gasket, Rocker Cover 2
18 BS-808389 Gasket Set, Engine 1
19 BS-809024 Kit, Carburetor Overhaul 1
20 BS-808399 Kit, Idle Mixture 1
21 BS-692077 Gasket, Carburetor Body 1
22 BS-690723 Pin, Float Hinge 1
23 BS-808798 Valve, Float Needle 1
24 BS-806126 Jet, Main (Standard) 1
25 BS-806128 Nozzle, Carburetor 1
26 BS-690721 Bushing, Choke Shaft 1
27 BS-806137 Washer, Sealing 1
28 BS-690722 Seal, Choke/Throttle Shaft 1
29 BS-806131 Seal, Choke/Throttle Shaft 1
30 BS-691516 Cap, Limiter 1
31 BS-808391 Gasket Set, Valve 1
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
GASKET SETS AND CARBURETOR OVERHAUL KIT
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
2
17
7
14
15
31
