Cub Cadet LT 2180 Parts Manual

-33-
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 731-3212 Cup Holder 1
2 631-3002 Cover, Implement Lift 1
3 703-2278B Fender 1
4 710-0751 Screw, Hex Cap, 1/4-20 x .62 6
5 710-0597 Screw, Hex Cap, 1/4-20 x 1.0 6
6 710-1268 Screw, Hex Tapp, #10 x .38 Lg 2
7 712-3027 Nut, Hex Flange Lock, 1/4-20 12
8 722-0258 Grommet, Insulator 6
9 723-3042 Bushing, Snap, 7/8 ID 1
10 735-3046A Pad, RH Foot 1
11 735-3047 Pad, LH Foot 1
12 736-3090 Washer, Flat, .255 x .72 x .06 6
13 750-3169 Spacer, .28 ID x .40 OD x .42 Lg 6
14 703-2279 Running Board w/Graphic 1
777S30170 Graphic, Warning 1
15 777D07926 Graphic, Rear Fender 1
16 703-2628 Bracket, Fender Reinforcement 2
17 710-0224 Screw, Hex Tapp, #10-16 x .5 4
FENDER AND RUNNING BOARD
