Cub Cadet LT 2180 Parts Manual

-35-
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 747-04196 Rod, Lift Link 1
2 703-2234 Bracket, LH Hanger 1
3 703-2804 Plate, Bearing Mounting 2
4 703-2832 Link, RH Lift 1
5 703-2833 Link, LH Lift 1
7 711-3319 Ferrule, Adjustment 1
8 712-0431 Nut, Hex Flange Lock, 3/8-16 5
9 712-3048 Nut, Hex Jam, 1/2-13 GR5 1
10 712-3083 Nut, Hex Insert Lock, 1/2-13 1
11 714-0145 Pin, Internal Cotter 1
12 736-0326 Washer, Flat, .5 x 1.5 x .15 3
13 736-3069 Washer, Flat, .531 x .875 x .15 2
14 738-0430 Bolt, Shoulder 2
15 738-0507B Bolt, Shoulder 3
IMPLEMENT LIFT HANGER
1
2
3
4
5
6
7
8
9
10
11
12
13
14
3
7
7
7
11
11
12
13
14
14
