Cub Cadet LT 2180 Parts Manual

-31-
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 603-0211 Bracket, Grille LH 1
2 603-0212 Bracket, Grille RH 1
3 603-04191 Bracket, Upper Hood 1
4 703-2396
777D07673
777X40079
Panel, RH Side
Graphic, LT2180
Strip, Protective
1
1
1
5 703-2397
777D07673
777X40079
Panel, LH Side
Graphic, LT2180
Strip, Protective
1
1
1
6 703-2398
777I20314
Grille
Graphic, Warning HOT
1
1
7 703-2465 Link, Short Hood 2
8 703-2466A Link, Long Hood 2
9 703-2495 Screen, LH Panel 1
10 703-2496 Screen, RH Panel 1
11 710-0351 Screw, Truss Mach Tapp, #10 x .50 6
12 710-0599 Screw, Hex Wash Hd Tapp, 1/4 x .50 4
13 712-3027 Nut, Hex Flange Lock, 1/4-20 8
14 712-0397 Nut, Wing, 1/4-20 2
15 726-0139 Nut, U-Type Speed, #10 2
16 625-04001A
725-0963
725-1649
777X41348
Headlight Assy (Includes Lamp and Socket)
Lamp, 12V
Socket, Lamp
Reflector, Headlight
1
2
2
1
17 732-0334 Spring, Compression, .50 OD x .50 4
18 732-1178 Spring, Hood Latch 1
19 736-0175 Washer, Spring, .265 x .562 x .025 8
20 736-0400 Washer, Flat, .218 x .62 x .063 2
21 738-3141 Bolt, Shoulder, .31 Dia x .75 Lg 2
22 748-3055 Bushing, Tapered 4
23 959-3747B
777D07681
777D07682
Hood, Series 2000
Graphic, Hood - RH
Graphic, Hood - LH
1
1
1
24 710-0436 Screw, Hex Tapp, 10-16 x .625 2
25 710-1005 Screw, Hex Wash Hd Tapp, 1/4-14 x .5 2
26 723-3061-19 Seal, Heat Baffle 19in
GRILLE, HOOD AND SIDE PANELS
