Cub Cadet LT 2180 Parts Manual

-37-
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 603-0181B Plate Assembly, Mounting 1
2 603-0199 Handle, Tension 1
3 703-2248 Bracket, Front Lift 1
4 603-0409B
777S30503
777S30014
777S30018
777D07929
777D07755
777I22056
Deck Assembly, 42"
Graphic, Danger Top/RH Deck
Graphic, Tension Lever
Graphic, Safety Top/LH Deck
Graphic, Cut
Graphic, 42" Cut
Graphic, Belt Route
1
1
1
1
1
1
1
5 703-1693A Bracket, Hinge Mounting 1
6 703-2559 Bracket, Handle Stop 1
7 703-3237 Shield, RH Pulley 1
8 703-2945 Shield, LH Pulley 1
9 710-0751 Screw, Hex Cap, 1/4-20 x .62 GR5 2
10 710-1260A Screw, Hx Wsh Hd Tapp, 5/16-18 x .75 3
11 710-3008 Screw, Hex Cap, 5/16-18 x .75 GR5 2
12 710-3178 Bolt, Carriage, 3/8-16 x .75 2
13 711-0792 Pin, Hinge, .25 Dia x 6.75 Lg 1
14 703-1890
737-0280
Wheel, Deck w/Fitting
Lube, Fitting
2
2
15 738-3056 Bolt, Shoulder, 1/2 x 2.5 2
16 711-3314 Pin, Roller, 1/2 Dia x 7.31 Lg 1
17 712-0431 Nut, Hex Flange Lock, 3/8-16 7
18 712-3004A Nut, Hex Flange Lock, 5/16-18 GR5 5
19 712-3006 Nut, Hex, 1/4-20 2
20 712-3048 Nut, Hex Jam, 1/2-13 GR5 2
21 712-3083 Nut, Hex Insert Lock, 1/2-13 2
22 714-3004 Pin, Cotter, 3/32 x 1.25 1
23 715-3003 Pin, Spirol Spring, 3/16 x .75 2
24 726-0106 Cap, Speed Nut 1
25 731-1032B Deflector Assy, (Incl. #5, 13, 24, 28, 45) 1
26 731-3005 Roller 1
27 732-0262 Spring, Extension, .88 OD x 6.12 1
28 732-0602A Spring, Torsion 1
29 732-3115 Spring, Extension, 1.25 OD x 8.15 1
30 732-3127 Spring, Compression 2
31 734-0973 Wheel, Deck, 5 in. Dia 2
32 736-0105 Washer, Bell, .401 x .870 x .063 2
33 736-0270 Washer, Bell, .265 x .75 x .062 4
34 736-0272 Washer, Flat, .510 x 1.0 x .060 4
35 736-0921 Washer, Lock, 1/2 2
36 738-0143 Bolt, Shoulder, .498 Dia x .340 Lg 1
37 738-507B Bolt, Shoulder, .50 Dia x .434 Lg 2
38 738-0533 Bolt, Shoulder, .498 Dia x 1.64 Lg 2
39 738-0572 Bolt, Shoulder, .375 Dia x 1.16 Lg 2
40 747-3172B Rod, Front Lift 1
41 747-3188 Pin, Mower Support 2
42 777S30284 Graphic, Danger 1
43 710-0599 Screw, Self Tapping, 1/4-20 x .5 5
44 783-1146A Skirt, Deck 1
45 726-0233 Nut, Push, 1/4 2
46 710-0180A Screw, Hx Cap Lock, 3/8-24 x .75 GR5 1
47 710-0902 Screw, Hex Cap, 3.8-24 x 3.75 GR5 1
48 712-3061 Nut, Hex Insert Lock, 3/8-24 2
49 750-3193 Spacer 1
42" DECK ASSEMBLY
