Cub Cadet LT 2180 Parts Manual

-39-
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 603-0857 Pivot Arm, Double Pulley 1
2 603-0181B Plate Assembly, Mounting 1
3 703-2463 Arm, Idler 1
4 710-0520 Screw, Hex Cap, 3/8-16 x 1.5 GR5 1
5 710-0923 Screw, Hex Cap, 5/8-18 x 3.0 GR5 1
6 710-1010 Screw, Hex Cap, 1/2-20 x 3.0 GR8 1
7 710-1260A Screw, Hex Wsh Hd Tap, 5/16-18 x .75 8
8 710-1336A Bolt, Spindle, 3/4-16 x 4.25 2
9 712-0239 Nut, Hex Center Lock, 1/2-20 1
10 712-0431 Nut, Hex Flange Lock, 3/8-16 1
11 712-3078 Nut, Hex Flange, 3/4-16 2
12 716-3020 Snap Ring, Internal 2
13 721-3018A Seal, Oil, 1.25 x 1.874 x .25 4
14 732-0262 Spring, Extension, .88 x 6.12 1
15 732-3115 Spring, Extension, 1.25 x 8.15 1
16 736-0100 Washer, Flat, .531 x 1.25 x .036 1
17 736-0179 Washer, Flat, .531 x 1.25 x .100 1
18 736-0237 Washer, Flat, .65 x 1.25 x .075 Hdn. 2
19 737-3000 Fitting, 3/16 Drive Lube 4
20 741-0338 Bearing, Flange, 3/4 ID x .53 Lg 2
21 741-1122 Bearing, .625 ID x 1.574 OD x 470 2
22 741-04089 Cone, Bearing 4
23 741-04091 Cup, Bearing 4
24 712-3087 Nut, Wing, 1/4-20 1
25 748-3065 Spacer, Deck Spindle 4
26 750-0656 Spacer, Idlr Brkt .50 ID x .75 OD x 2.25 1
27 750-3132 Spacer, Pulley .635 ID x .88 OD x 1.25 1
28 750-3190A Spacer, Bearing, .780 x .963 x .777 2
30 754-3073 Belt, Spindle, A-Section x 61 Lg 1
31 754-04041 Belt, PTO, B-Section x 111.2 Lg 1
32 756-0627B Pulley, Flat Idler, 3.5 OD 1
33 756-3114 Pulley, Double
(737-3000 Lube Fitting Not Included)
1
34 756-3089 V-Pulley, 4.0 Dia 2
35 759-3830 Blade, 3 In One, 21.20 Lg 2
36 618-3129B Spindle, Blade 2
37 731-2363 Plug, Mulch 1
38 710-0134 Screw, Carriage, 1/4-20 x .62 1
42" SPINDLE ASSEMBLY
