-16-
REF.
NO.
PART
NUMBER CODE DESCRIPTION QTY.
† 629-3060 Harness, Main Wire ....................... 1
2 703-4104 0637 Strap, Battery Holddown ................ 1
3 703-4131 Bracket, Fuse Center ..................... 1
4 710-0206 Screw, Hex Cap, 1/4-10 x .875 GR5 2
5 710-0599 Screw, Hex Wash Hd. Tapp ..........
1/4-20 x .5
2
6 712-0324 Nut, Hex Nylon Insert Lock, 1/4-20 2
7 712-0421 Nut, Wing w/Bell Washer, 5/16-18 2
8 725-3174 Battery, 500 cca Dry ...................... 1
9 725-3273 Switch, PTO Reverse Override ...... 1
10 747-3433 Rod, Battery Holddown .................. 2
BATTERY AND ELECTRICAL
2
3
4
5
6
7
8
9
10
† Not Shown
To Next Page
