Cub Cadet SERIES 7000 7264 User Manual

-3-
REF.
NO.
PART
NUMBER CODE DESCRIPTION QTY.
1 603-0666 Frame ............................................. 1
2 703-3503A Lever, Hood Latch .......................... 1
3 703-3497A Bracket, Running Board Mtg. LH .... 1
4 703-3379A Bracket, Running Board Mtg. RH ... 1
5 703-05137 Bracket, Hood Latch Mtg. ............... 1
6 710-3083 Screw, Hex Cap, .............................
5/16-18 x 1.375 GR5
3
7 710-0451 Screw, Carriage, .............................
5/16-18 x .75
2
8 710-1260A Screw, Hex Wash. Hd. ...................
5/16-18 x .75
6
9 712-3004A Nut, Hex Flange Lock, 5/16-18 ....... 5
10 726-0455 Latch, Hood .................................... 1
FRAME
1
2
3
4
5
6
7
8
9
10
8
9
9
