-36-
COOLING
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
12
15
12
1
20
21
22
23
24
25
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 BS-820031 Screw, Hex, 6mm ............................ 4
2 BS-820034 Screw, Hex, ..................................... 4
3 BS-820022 Screw, Hex, 8mm ............................ 2
4 BS-820185 Screw, Metric .................................. 1
5 BS-820181 Nut, Hex Metric ............................... 1
6 BS-825064 Thermostat ...................................... 1
7 BS-820271 Belt, V ............................................. 1
8 BS-820208 Switch, Coolant Temperature ......... 1
9 BS-820052 Plug ................................................. 1
10 BS-820182 Plug ................................................. 1
11 BS-825454 Fan, Radiator .................................. 1
12 BS-820093 Gasket, Outlet ................................. 1
13 BS-820095 Pulley, Pump ................................... 1
14 BS-825267 Housing, Outlet ............................... 1
15 BS-820098 Gasket, Inlet Housing ...................... 1
16 BS-825051 Housing, Inlet .................................. 1
17 BS-820100 Gasket, Water Pump ....................... 1
18 BS-825160 Connector, Coolant Temp. Switch .. 1
19 BS-825265 Pump, Water ................................... 1
20 BS-825462 Tank, Reserve ................................. 1
21 BS-825461 Cap, Reserve Tank ......................... 1
22 BS-820257 Clamp, Hose ................................... 2
23 BS-825314 Bracket, Reserve Tank Mtg. ........... 1
24 BS-820034 Screw, Mtg. Bracket ........................ 1
25 BS-820011 Nut, Mtg. Bracket ............................ 1
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
