CUE touchCUE-5 - Page 10

Wired Touch Panels - User Manual
10© CUE, a.s. | All Rights Reserved.
touchCUE-7-B
LCD display with touch sensor
Microphone
Network connector
Front View Rear View
Top View
Button System Default
Speakers
Bottom View
Fixing screw
199 mm
120 mm13 26
160 mm
Wall adapter
106 mm
Light sensor
Proximity sensor transmitter
Proximity sensor receiver
touchCUE-10-B
Proximity sensor transmitter
Bottom view
Light sensor
Proximity sensor receiver
Top view
Rear view
LED indicators
Side viewSide view
Fixing screw
LCD display
with touch sensor
16
167 mm
268 mm
Wall adapter 150 x 160 mm
Network connector
Front view
Microphone
37 mm
Speakers
