71
01021076
Item
Part
Number
Description
* 01023111 HE Indoor Control Valve, Dowflow, Complete
* 01023115 HE Indoor Control Valve, Upflow, Complete
1 01023020 Valve Body
2 01025267
Piston Rebuild Kit, Includes 6ea Standard Piston
assemblies and 1ea Brine Piston Assembly
3 P1022786 Brine Piston w/80 Duro Quad Seal, HE 1”, 5ea
4 01020440 Gear Box Assembly, Downflow
01022234 Gear Box Assembly, Upflow
5 01020240 Gearmotor
6 P1020415 Retainer, Gearmotor, 10ea
7* 01020420 Wire Harness w/ Position Sensor, Indoor
8 01022735 Wire Harness, Motor
9 P1020433 Position Sensor Screw, 10ea
10 P1020517 Gear Box Assembly Screw, 10ea
11 P1020289 Dial-a-Softness Knob, 10ea
12 P1020427 Dial-a-Softness Assembly w/ O-Rings, 10ea
13 P0440268 O-Ring, Brine & Drain Elbow, 10ea/Kit
14 P1020487 Eductor Plug Assembly w/ O-Rings, 10ea
15 P1020290 Eductor Plug Retainer, 10ea
16 P1023051 Dial-a-Softness Locking Plug, 10ea
17 P1020291 Dial-a-Softness Locking Plug Retainer, 10ea
18 P1020581 Brine Elbow Assembly, 10ea
19 P1020432 Retainer, Brine & Drain Elbow, 10ea
20 P1023021 Drain Elbow Assembly, 10ea
23* 01023014 Enclosure Frame, Indoor
24 P0331635 Backwash Flow Control, #2 Brown, 10ea
P0331636 Backwash Flow Control, #3 Green, 10ea
P0401031 Backwash Flow Control, Black, 10ea
25* 01023066 Cover, Hood, Compact, HE Control, Indoor
26* —
Hood, Compact, HE Control, Indoor (not avail-
able for sale), Kit
28 P0318383 Enclosure Screw, 10ea/Kit
29 P1023122 Retainer for Enclosure Screw, 10ea/Kit
30 P1020617 Nut for Enclosure Screw, 10ea/Kit
31* P1000372 Strain Relief Fitting, Indoor 25ea/Kit
32* P1006498 Plug, Indoor 10ea/Kit
34 P1021162 O-ring, Eductor Plug Assembly, Large, 10ea/Kit
35 P1020424 O-ring, Eductor Plug Assembly, Small, 10ea/Kit
37 01017134 Power Cord
39* 01023448
Electronics Enclosure Kit less Circuit Board,
Indoor
40* 01023447 Replacement Circuit Board, Indoor
41* P1023112 Circuit Board Label, Indoor, 10ea/Kit
42* P1020497 Keypad with Connector, indoor 10ea/Kit
45 P1022796
Eductor Throat with O-rings, Downflow, Tan,
10ea
P1022723
Eductor Throat with O-rings, Downflow, Blue,
10ea
P1023712
Eductor Throat with O-rings, Upflow, Gray,
10ea
P1023713
Eductor Throat with O-rings, Upflow, White,
10ea
46 P1020603 Eductor Throat O-ring, Large, 10ea/Kit
47 P1020428 Eductor Throat O-ring, Small, 10ea/Kit
48 P1013894 Eductor Nozzle w/ O-ring, Blue, 10ea
P1013895 Eductor Nozzle w/ O-ring, Beige, 10ea
P1024333 Eductor Nozzle w/ O-ring, Green, 10ea
49 P0308438 O-ring, Eductor Nozzle, 10ea/Kit
50 P1020256 Screen, 10ea/Kit
51 01014153
Tank Adapter Assy, 1” valve to tank less
O-Rings
52 01013958 Tank Adapter, 1” Valve, Kit
53 P1013959 Tank Clamp, 1” Valve, Kit
Item
Part
Number
Description
54 P1013669 Tank Clamp Pin, 1” Valve, 10ea/Kit
55 P0318383
Tank Clamp Screw, 1” Valve/3/4” bkt, 10ea/
Kit
56 P1014848 O-ring, Large, Valve to Tank Adapter, 25ea
57 P0440052 O-ring, Valve Adapter to ACME Tank, 25ea
60 P1020431 Main Piston O-ring, 25ea/Kit
61 P1025199 Main Piston Quad Ring, 25ea/Kit
62 P1020426 Brine Piston O-ring 25ea/Kit
63 —
Brine Piston Quad Ring (not available for
sale), Kit
64 P1020252 Main Piston Spring, 10ea
65 P1020286 Brine Piston Spring 10ea
69 01018760 Bypass Valve, Rotary
70 P1009075 Retaining Clip, 1” Bypass valve, 10ea/Kit
71 01014033 Coupling Kit - 1” Bypass
72 P1009099 O-ring, Couplings/Meters, 50ea/Kit
82 01026849 Meter Kit Assembly, HE 1”, LF
83* 01023117 Wire Harness, Meter, 28"Long, Indoor
84 P1023699
Half Ball w/ Post, Upflow Only, 10ea (only
upflow models)
85 P1023695
Spring, Upflow Only, 10ea (only upflow
models)
*** P0451701 Hose Clamp, Drain, 25ea
*** 01018249 1¼” Straight Through Adapter
*** 01018755 Rebuild Kit - 1”/1¼” Rotary Bypass
*** P1016467
Replacement O-Ring for Bypass Valve Stem,
50ea/Kit
*** 01010783 1” Copper Adapter Kit, (1” Bypass)
*** 01016564 3/4” Copper Adapter Kit (1” Bypass)
*** 01016565 3/4” Elbow Copper Adapter Kit (1” Bypass)
*** P1018757
1” NPT Female Elbow Kit (1” Rotary Bypass),
10ea
*** P1009856
Gasket, Copper Plumbing Adapters, 25ea
*** 01018133
Transformer, Dual Output
*** 01020620
Transformer, Dual Output w/ 6' Power Cord
(optional)
*** 01020748
Auxiliary Board (optional)
Outdoor Part Numbers
** 01025717
HE Outdoor Control Valve, Downflow,
Complete
** 01025718
HE Outdoor Control Valve, Upflow, Complete
86** —
Wire Harness w/Position Sensor, Outdoor
(not available for sale), Kit
87** 01024917
Frame, Hood Compact, HE Control, Outdoor
88** 01024946
HE 1” Control Valve Cover, Outdoor
89** —
Compartment Plate w/Gaskets, Outdoor (not
available for sale), Kit
90** —
Enclosure w/Decal and Keyboard, Outdoor
(not available for sale), Kit
91** P1025274
Strain Relief Fitting, Outdoor, 10ea/Kit
92** P1025277
Liquid Tight Hole Plug, Outdoor, 10ea/Kit
93** 01025650
Electronics Enclosure Kit less Circuit Board,
Outdoor
94** 01020745
Replacement Circuit Board, Outdoor
95** 01025282
Wire Harness, Meter, 28” Long, Outdoor
96** P1023200
Compartment Plate Screw, Outdoor, 10ea/Kit
** 01025561
Outdoor Transformer, Dual Output w/6” Pow-
er Cord (optional)
** P1025264
Strain Relief Fitting, Outdoor, 10ea
*Indoor ONLY Part Number
**Outdoor ONLY Part Number
*** Not shown
