The controller display, as well as the Remote Display (if connected), may display the following errors.
PROBLEM FOUND
APR-01-13 10:01A
1. When the controller identifies an error, it is programmed to attempt
to correct the error without user input. If the problem persists, the
HOME SCREEN displays PROBLEM FOUND. Press to display
the first error present.
REPLACE FILTER
MEDIA
2. Press to display any additional errors present.
-->CLEAR ERRORS
3. Press and to view action: CLEAR ERRORS, GO TO MENU,
or EXIT. If you select CLEAR ERRORS, the controller checks the
error status and attempts to clear the error. If the error still exists, the
home screen displays PROBLEM FOUND. If the error no longer ex-
ists the screen displays SYSTEM OK.
-->GO TO MENU
4. Press to select CLEAR ERRORS, GO TO MENU, or EXIT.
Error Reason for Error Comment/ Clearing Error Message
Aqua Salt Err
Aqua-Sensor did not detect brine
during the regeneration cycle.
Check brine tank and add salt if necessary. Check Z
ratio of the Aqua-Sensor at Main Menu/Advanced/
Diagnostics/Check Sensors
Aqua Sens Probe
An Aqua-Sensor was “Installed” but
main board detects the Aqua-Sensor
is not connected. The board might not
be detecting the 2.5V power supply
Check connection of Aqua-Sensor to the main board.
Auxiliary Alarm
Auxiliary Input is configured as alarm
contacts and was closed for the pre-
scribed amount of time.
Check the device that is connected to the Auxiliary
Input.
Brine Blocked
The brine draw rate of water to the
brine tank was longer than normal.
Check brine line for blockages or air leaks. Check
eductor and eductor screen for blockages
Brine Overfill
Too much water in brine tank.
Plugged drain line flow control (Unit
will not draw brine).
Plugged eductor system (Unit will not
draw brine).
Slow leak to brine line.
Faulty eductor piston.
Power outage while control was in
refill position.
Check eductor; check for brine draw.
Clean drain line flow control.
Clean eductor screen and nozzle
Replace eductor piston
Call Culligan at
xxx-xxx-xxxx
This message is displayed if an error
has been detected that requires ser-
vicing and no modem installed in the
system.
Call the number shown. If possible, place this call using
a phone that will allow you to see and enter changes to
the main controller if required by the service technician
during the call
Check Brine Tank
Aqua-Sensor did not detect brine
during the regeneration cycle.
Check brine tank and add salt if necessary. Check Z
ratio of the Aqua-Sensor at Main Menu/ Advanced /
Diagnostics/ Check Sensors
Check SBT Sensor
SBT sensor indicated improper sig-
nals at the beginning of the refill
cycle.
The SBT sensor may have an obstruction causing the
optical detection paths to all be blocked at once; possi-
ble electrical open/short in SBT pcb or wire harness.
Error Codes
