Installing Accessories 39
Cat. No. 01029343
Figure 54.
6. Make sure all the coupling o-rings are fully inserted into the manfold.
7. Screw manifold back onto the valve body. Be careful not to pinch any of the o-rings
8. Screw the cover onto the manifold. (16 screws)
9. Reconnect the tubing (see page 18).
Proper position
of non-hardwater
bypass plug
5. Insert non-hardwater bypass plug on top
of the hardwater bypass piston.
