Culligan CTM 21 - Page 51

Service and Repair 47
Cat. No. 01029343
Push all the pistons from the bottom and remove from the top side of the valve body.
Figure 62.
Load all pistons (8) in from the top and push to lower into the fully seated position. Flip the valve body onto its top (flow
valves up)
Figure 63.
CAUTION! Do NOT lubricate T-Seals!
Lubricate o-rings
