46 Culligan® Culligan Top Mount (CTM) Water Filters
46 Cat. No. 01029343
Figure 60.
Figure 61.
Using pliers grab the rib on the
top of the piston, while removing
the screws from the bottom of
the piston and removing the flow
valve assemblies
Lower Flow Valve
Small Flow Valve Assemblie (3)
Large Flow Valve Assemblies (5)
T-Seal
Upper Flow Valve
SS Insert
Lower Flow Valve
Small Flow Valve Assemblie (3)
Large Flow Valve Assemblies (5)
T-Seal
Upper Flow Valve
SS Insert
#2 screws
#3 screws
