50 Culligan® Culligan Top Mount (CTM) Water Filters
50 Cat. No. 01029343
Reassemble Valve
Figure 68.
Figure 69.
1. Lubricate
T-Seal
Flow Port
2. Be certain o-rings are
all in place on the tank
adapter before mating
with the valve body.
NOTE Remove excess water from the tank adapter to prevent o-ring(s)
from floating during attachment with the valve body.
Pry Point
