68 Culligan® Culligan Top Mount (CTM) Water Filters
68 Cat. No. 01029343
Item Part No. Description
— —
Control Valve, Single Tank, Downflow, No
Hard Water Bypass
— —
Control Valve, Multi Tank, Downflow, No
Hard Water Bypass
1
— —
Control Valve, Timeclock, Single Tank,
Downflow, No Hard Water Bypass
1 01029565 Kit, Brine Elbow Assembly
3 — Clip, Brine Adapter
3
4 — Clip, Drain Line Flow Adapter
3
5 01029469 Kit, Drain Line Flow Control, 60K Units
01029460 Kit, Drain Line Flow Control, 90K-600K Units
6 P1028331
Inserts, Drain Line Flow Control, 0 GPM,
Black, 10 PK
P1028332
Inserts, Drain Line Flow Control, 5 GPM,
Blue, 10 PK
P1028333
Inserts, Drain Line Flow Control, 8 GPM,
Green, 10 PK
P1028334
Inserts, Drain Line Flow Control, 10 GPM,
Orange, 10 PK
7 01029851 No Hard Water Bypass Plug (for conversion)
8 01029564 Eductor Port Cap
10 P1028338 Eductor Throat,Blue #0,w/O-Rings, 10 PK
11 — Clip, Eductor Plug Cap
3
12 01029567 Kit, Valve Clamp
13 P1023559 O-Ring, 10 PK
14 P1023560 O-Ring, 10 PK
15 P1023558 O-Ring, 10 PK
16 01019742 Upper Disperser
17 01028328 Kit, Flow Meter Assembly
2
01028052 Kit, Coupler Assembly
4
18 01029566 Kit, PRV Assembly
2
19 01029511 Kit, Vacuum Breaker Assembly
2
20 — Clip, Vacuum Breaker/PRV
3
21 01029551 Vacuum Breaker/PRV Port Plug
4
01029582 Vacuum Breaker & PRV Port Plug
22 01029580 Kit, Core Control Valve Replacement
23 01029584 Screws, Top Manifold and Pilot Enclosure
24 01029562 Motorized Ball Valve #1 (Ports 4, 5, 6)
1
25 01029563 Motorized Ball Valve #2 (Ports 1, 2, 3)
1
26 01029583 Pilot Valve Rebuild Kit
27 — Kit, Position Sensor
3
28 — Kit, Pilot Body and O-Rings
3
29 — Kit, Position Indicator Wheel
3
30 — Gear, Pilot Drive Spool, CTM
3
31 01029558 Kit, Motor Assy, CTM
3
32 01029560 Housing, Top, Pilot Body, Downflow
3
33 01029561 Kit, Enclosure, Pilot Drive
3
34 01029576
Kit, Piston Actuator w/O-Rings, Flow Valves
and T-Seals
35 01029577 Kit, Piston O-Rings and T-Seals
Item Part No. Description
36 01029578
Kit, Seals for upper, lower and external
valve body
37 01029500 1.5” NPT Inlet/Outlet Plumbing Adapter
01029502
1.5” NPT Inlet/Outlet Plumbing Adapter w/
Ports
01029512 1.5” BSPT Inlet/Outlet Plumbing Adapter
01029514
1.5” BSPT Inlet/Outlet Plumbing Adapter w/
Ports
01029501 2” NPT Inlet/Outlet Plumbing Adapter
01029503
2” NPT Inlet/Outlet Plumbing Adapter w/
Ports
01029513 2” BSPT Inlet/Outlet Plumbing Adapter
01029515
2” BSPT Inlet/Outlet Plumbing Adapter w/
Ports
38 00303177
Tubing, 1/4”, PE Black, 1 ft. (for Pilot
Valve)
5
00402184 Tubing, 1/4”, PE Blue, 1 ft. (for Pilot Valve)
5
39 01030179 Cable Harness, Ball Valves, Valve Mount
1, 5
01030177
Cable Harness, Ball Valves, Remote
Mount
1, 5
40 01028019 Kit, Clips (Contains Item 3, 4, 11, and 20)
1
Multi-Tank Only
2
Not designed to operate with Timeclock Control Valves.
3
A part of a Kit
4
Timeclock Only
5
Not Shown
