CTM Parts List 69
Cat. No. 01029343
Valve Service Rebuild Kits
More than one option exists for rebuilding the CTM valve. Select the kit that best suits the customer’s rebuilding plans and
costs.
CTM Valve O-Ring Kit
Contains all the sealing o-rings needed in the valve. Use with the Piston Rebuild Kit, Piston Replacement Kit or the Valve
Core Replacement Kit.
Item Part No. Description Qty
— 01029578 Seals for upper, lower and external valve body Kit —
1 — O-Ring,ARP#221,EPDM 3
2 — O-Ring,ARP#224,EPDM 1
3 — O-Ring,ARP#229,EPDM 4
4 — O-Ring,ARP#235,EPDM 8
5 — O-Ring,ARP#226,EPDM 6
6 — O-Ring,ARP#210,EPDM 1
7 — O-Ring,ARP#225,EPDM 4
8 — O-Ring,ARP#230,EPDM 2
9 — O-Ring,ARP#218,EPDM 2
10 — O-Ring,ARP#223,EPDM 2
11 — O-Ring,ARP#228,EPDM 5
12 — O-Ring,ARP#232,EPDM 1
13 — O-Ring,ARP#137 ,EPDM (Flow Meter 4
14 — O-Ring,ARP# 229 ,EPDM (Drain Adapter 2
15 — O-Ring,ARP#121 ,EPDM (PRV/VB 2
CTM Piston Rebuild Kit
Contains all the o-rings and T-seals needed to rebuild the 8 piston assemblies only. A Valve O-Ring Kit is also needed.
Item Part No. Description Qty
— 01029577 Piston O-Rings and T-Seals Kit —
1 — Seal,T-Shape,Valve (2.00”) 4
2 — Seal,T-Shape,Valve (1.50”) 1
3 — Seal,T-Shape,Valve (0.75”) 3
4 — O-Ring,ARP#110,EPDM 6
5 — O-Ring,ARP#112,EPDM 10
6 — O-Ring,ARP#221,EPDM 3
7 — O-Ring,ARP#224,EPDM 1
8 — O-Ring,ARP#229,EPDM 4
