TABLE 8 - Brine Valve "A" Dimension
REFILL TIME (MIN) BRINE TANK “A” DIMENSION
POUND STANDARD FAST 160 LB 250 LB 375 LB
SALT (0.45 gpm) (0.80 gpm) (13") (16") (18")
3 2.23 1.30 6 5-1/4 4-1/2
4 3.08 1.73 7-3/4 6-5/8 5-1/2
5 3.83 2.17 9-1/2 8 6-1/2
6 4.62 2.63 11-1/4 9-3/8 7-1/2
7 5.38 3.03 13 10-7/8 8-1/2
8 6.15 3.47 14-3/4 12-1/4 9-1/2
9 6.92 3.90 16-1/2 13-5/8 10-1/2
10 7.70 4.32 18-1/4 15 11-1/2
11 8.47 4.75 20 16-3/8 12-1/2
12 9.23 5.18 21-3/4 17-3/4 13-1/2
13 10.00 5.63 23-1/2 19-1/8 14-1/2
14 10.77 6.07 25-1/4 20-1/2 15-1/2
15 11.53 6.50 — 21-7/8 16-1/2
16 12.30 6.93 — 23-1/4 17-1/2
17 13.08 7.35 — 24-5/8 18-1/2
18 13.85 7.78 — 26 19-1/2
19 14.62 8.22 — 27-3/8 20-1/2
20 15.38 8.65 — 28-3/4 21-1/2
21 16.15 9.08 — — 22-1/2
22 16.92 9.53 — — 23-1/2
23 17.68 9.95 — — 24-1/2
24 18.47 10.38 — — 25-1/2
"A" DIMENSION CHARTS/REFILL RATES 25
