Culligan MEDALLIST SERIES Installation And Operation Instructions With Parts List

Bypass
Although the filter’s control valve has a feature which makes unfiltered water available during backwash, a separate manual
bypass is recommended to permit unfiltered water to be used in those lines which cannot be bypassed when the filter is plumbed
in, or to permit use of water in the event the unit must be removed from service for any reason.
The 3/4” Medallist Control includes a Cul-Flo-Valv® bypass with 3/4” NPT connections, PN 01-0102-38, (Figure 5). Other
available sizes:
Part No. Description Size
01012488 Cul-Flo-Valv Bypass 3/4-inch Sweat
01010237 Cul-Flo-Valv Bypass 1-inch NPT
The Medallist Plus includes a Cul-Flo Valve bypass with 1 1/4” NPT connections. The following optional sweat connection kits are
available:
Part No. Description
01010783 1” Sweat Copper Adapter Kit
01016564 3/4” Sweat Copper Adapter Kit
01016565 3/4” Elbow Sweat Copper Adapter Kit
7 Culligan Medallist Series
®
Water Filters

Culligan MEDALLIST SERIES Specifications

General

Type	Water Softener
Flow Rate	Up to 12 gallons per minute
Resin Type	High-capacity resin
Dimensions	Varies by model
Weight	Varies by model
Tank Material	Fiberglass
