Location
Space requirements - Allow 6-12 inches (15-30 cm) behind the unit for plumbing and drain lines.
Floor surface - Choose an area with solid, level floor free of bumps or irregularities.
Drain facilities - Choose a nearby drain that can handle the rated drain flow (floor drain, sink or stand pipe). Refer to the Drain
Line Chart, Table 1 (page 12), for maximum drain line length.
Electrical facilities - A 10-foot cord and wall mount plug-in transformer are provided. The customer should provide a receptacle,
preferably one not controlled by a switch that can be turned off accidentally. Observe local electrical codes.
Tools and Materials
The following tools and supplies will be needed, depending on installation method. Observe all applicable codes.
All Installations
• Safety glasses
• Phillips screwdrivers, small and medium tip
• Gauge assembly (PN 00-3044-50 or equivalent)
• Silicone lubricant (PN 00-4715-07 or equivalent) - DO NOT USE PETROLEUM-BASED LUBRICANTS
• A bucket, preferably light-colored
• Towels
Special Tools
• Torch, solder and flux for sweat copper connections
• Threading tools, pipe wrenches and thread sealer for threaded connections
• Saw, solvent and cement for plastic pipe connections
Materials
• Drain line, 1/2” (PN 00-3030-82, gray, semi-flexible; or PN 00-3319-46, black, semi-rigid; or equivalent)
• Thread sealing tape
• Pressure reducing valve (if pressure exceeds 125 psi)
• Pipe and fittings suited to the type of installation
• Plastic pipe (if permitted by local plumbing codes) — saw, solvent cement and rags
If the household plumbing is galvanized and you intend to make the installation with copper, or vice versa, obtain dielectric unions
to prevent galvanic (dissimilar metal) corrosion.
All installations will require 1/2” drain line, (PN 00-3030-82, gray, semi-flexible; or PN 00-3319-46, black, rigid). Obtain slightly
more than you think you will need to cover for the elevation over doorways and so on.
Note: The filter works on 24 volt - 60 Hz electrical power only. Be sure to use the included transformer. Be sure the electrical
outlet and transformer are in an inside location to protect from moisture. Properly ground to conform with all governing codes
and ordinances.
Note: P.N. 01012956 plug-in transformer is rated for indoor installations only.
P.N. 01015972 plug-in transformer is rated for indoor/outdoor installations.
Preparation 6
Note: Most codes require an anti-siphon device or air gap. Observe all local plumbing codes and drain restrictions. The system
and installation must comply with all state and local laws and regulations.
For installations in Massachusetts, the Commonwealth of Massachusetts Plumbing code 248 CMR shall be adhered to.
Consult with your licensed plumber for installation of this system.
